148B6115 DANFOSS REFRIGERATION Multifunction valve body, SVL 125
148B6115
DANFOSS REFRIGERATION
Multifunction valve body, SVL 125
SVL125 ANSI VALVE HOUSING STR PS52
Multifunction valve body, SVL 125, SVL Flexline, Direction: Straightway, 125.0 mm
Home > DANFOSS REFRIGERATION
* Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS REFRIGERATION
Best sellers
▲More info
▲Used for product: SVL 125
Product details
| Gross weight | 33.5 Kg |
| Net weight | 26.16 Kg |
| Volume | 108.1 Liter |
| EAN | 5702428485869 |
| Gross weight | 33.5 Kg |
| Net weight | 26.16 Kg |
| Volume | 108.1 Liter |
| EAN | 5702428485869 |
| Approval | CE UKCA |
| Body material | Steel |
| Brand | SVL Flexline |
| Connection material | Steel |
| Connection standard | ASME B 36.10M SCHEDULE 40 |
| Direction | Straightway |
| EU RoHS compliance | No - out of scope |
| Flow direction | Bi-flow |
| Flow direction indicator | Embossed 1-way arrow |
| Fluid Group | 1 2 |
| In scope of WEEE and contain batteries | No |
| Inlet connection size [in] | 5 in |
| Inlet connection size [mm] | 125 mm |
| Inlet connection type | Butt weld |
| Max. Working Pressure [bar] | 52 bar |
| Max. Working Pressure [psig] | 754 psig |
| Outlet connection size [in] | 5 in |
| Outlet connection size [mm] | 125 mm |
| Outlet connection type | Butt weld |
| Packing format | Single pack |
| Parts Program name | CHV-X FIA SCA-X SVA-S / SVA-L |
| PED category | III |
| Product accessories | SVL Flexline accessories |
| Product description | Valve house |
| Product group | Multifunction valves |
| Product Name Description | Multifunction valve body |
| Quantity per packing format | 1 pc |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| Refrigerants | R1233zd(E) R1234yf R1270 R134a R152a R22 R23 R236fa R290 R32 R402A R404A R407A R407C R407F R410A R417A R427A R438A R448A R449A R452A R513A R600a R717 R744 R113 R114 R1234ze(E) R125 R1336mzz(Z) R170 R227ea R401A R402B R407B R407H R408A R409A R421A R422A R422B R422D R444B R447A R449B R450A R454B R455A R502 R503 R600 RE170 R507A R1150 R245fa R413A R442A R447B R452B R454A R454C R463A R512A R513B R515A R515B R516A R508B |
| Serviceable | SVL Flexline spare parts |
| Temperature range [°C] [max] | 150 °C |
| Temperature range [°C] [min] | -60 °C |
| Temperature range [°F] [max] | 302 °F |
| Temperature range [°F] [min] | -76 °F |
| Type | SVL 125 |
| Used for product | SVL 125 |
| Approval | CE UKCA |
| Body material | Steel |
| Brand | SVL Flexline |
| Connection material | Steel |
| Connection standard | ASME B 36.10M SCHEDULE 40 |
| Direction | Straightway |
| EU RoHS compliance | No - out of scope |
| Flow direction | Bi-flow |
| Flow direction indicator | Embossed 1-way arrow |
| Fluid Group | 1 2 |
| In scope of WEEE and contain batteries | No |
| Inlet connection size [in] | 5 in |
| Inlet connection size [mm] | 125 mm |
| Inlet connection type | Butt weld |
| Max. Working Pressure [bar] | 52 bar |
| Max. Working Pressure [psig] | 754 psig |
| Outlet connection size [in] | 5 in |
| Outlet connection size [mm] | 125 mm |
| Outlet connection type | Butt weld |
| Packing format | Single pack |
| Parts Program name | CHV-X FIA SCA-X SVA-S / SVA-L |
| PED category | III |
| Product accessories | SVL Flexline accessories |
| Product description | Valve house |
| Product group | Multifunction valves |
| Product Name Description | Multifunction valve body |
| Quantity per packing format | 1 pc |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| Refrigerants | R1233zd(E) R1234yf R1270 R134a R152a R22 R23 R236fa R290 R32 R402A R404A R407A R407C R407F R410A R417A R427A R438A R448A R449A R452A R513A R600a R717 R744 R113 R114 R1234ze(E) R125 R1336mzz(Z) R170 R227ea R401A R402B R407B R407H R408A R409A R421A R422A R422B R422D R444B R447A R449B R450A R454B R455A R502 R503 R600 RE170 R507A R1150 R245fa R413A R442A R447B R452B R454A R454C R463A R512A R513B R515A R515B R516A R508B |
| Serviceable | SVL Flexline spare parts |
| Temperature range [°C] [max] | 150 °C |
| Temperature range [°C] [min] | -60 °C |
| Temperature range [°F] [max] | 302 °F |
| Temperature range [°F] [min] | -76 °F |
| Type | SVL 125 |
| Used for product | SVL 125 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| 148B6115 148B6115 EN_148B5470.pdf | 5 Mbytes |
 |
