BCH-350H- 4 BK
5452010
PHOENIX_CONTACT
100
Housing base,nominal Current: 8 A,rated Voltage (III/2): 160 V,N. º poles: 4,Pitch: 3.5 mm,Color: black,contact Surface: Tin,Assembly: wave Soldering
Connectors > Printed circuit board connector
PCB Connectors (PCC)
* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Thank you for your interest in our products; we hope the delivery time indicated is to your convenience.
While the order is being processed you can select the type of shipment that best suits your needs: 24-hour air express, standard 48-72 hour land, etc.
Key order | Five million four hundred fifty two thousand ten |
---|---|
Packing unit | 100 pcs |
Key selling | AAYBFA - |
Minimum order quantity | 100 pcs |
EAN | Four trillion forty six billion three hundred fifty six million eight hundred fifty five thousand seven hundred sixteen |
Unit weight (excluding packaging) | 1,040 g |
Tariff number tariff | Eighty five million three hundred sixty six thousand nine hundred ninety |
Country of origin | CN (China) |
Length [ l ] | 9,2 mm |
---|---|
Width | 15.4 mm |
Step | 3.5 mm |
Average | 10.5 mm |
Width [ w ] | 15.4 mm |
Height [ h ] | 10.8 mm |
Height of construction | 7.4 mm |
Length of the pin welding | 3.4 mm |
Dimensions of pin | 0.8 x 0.8 mm |
Length | 9,2 mm |
Family of articles | BCH-H |
---|---|
Group insulating material | I |
Transient voltage design (III/3) | 2.5 kV |
Transient voltage design (III/2) | 2.5 kV |
Transient voltage design (II/2) | 2.5 kV |
Tension and sizing (III/3) | 160 V |
Tension and sizing (III/2) | 160 V |
Tension and sizing (II/2) | 320 V |
Connection according to standard | EN-VDE |
Nominal current IN | 8 To |
Isolation | PA |
Class of flammability according to UL 94 | V0 |
Color | black |
Number of poles | Four |
Connection according to standard | EN-VDE |
---|---|
CUL | |
Class of flammability according to UL 94 | V0 |
China RoHS | Space of time for the intended use: unlimited = FEUP-e |
---|---|
No dangerous substances above the thresholds |
