SLN-0000037
682033
OMRON
1
MicroHAWK, ID/MV-40, SXGA, HD, LED blanc, caméra dual-boot avec accessoires
Détecteurs > Accessoires pour détecteur
Lecteurs de codes à barres industriels > Lecteurs de codes barres et caméras intelligentes
* Produit neuf dans son emballage d'origine avec toutes les garanties et les certifications émises par OMRON
Merci de vous intéresser à nos produits, nous espérons que le délai indiqué soit de votre convenance.
Pendant le traitement de la commande, vous pouvez sélectionner le type d'envoi qui vous convient. Aérien Express 24Hrs, Terrestres Standard 48/72Hres, etc.
Specifications | Order code | |||||
---|---|---|---|---|---|---|
Heavy Duty | Normal Duty | Standard | Built-in filter | |||
1x200 V | 0.12 kW | 0.8 A | 0.18 kW | 0.8 A | VZAB0P1BAA | VZAB0P1EAB |
0.25 kW | 1.6 A | 0.37 kW | 1.6 A | VZAB0P2BAA | VZAB0P2EAB | |
0.55 kW | 3.0 A | 0.75 kW | 3.5 A | VZAB0P4BAA | VZAB0P4EAB | |
1.1 kW | 5.0 A | 1.1 kW | 6.0 A | VZAB0P7BAA | VZAB0P7EAB | |
1.5 kW | 8.0 A | 2.2 kW | 9.6 A | VZAB1P5BAA | VZAB1P5EAB | |
2.2 kW | 11.0 A | 3.0 kW | 12.0 A | VZAB2P2BAA | VZAB2P2EAB | |
4.0 kW | 17.5 A | 5.5 kW | 21.0 A | VZAB4P0BAA | − | |
3x200 V | 0.12 kW | 0.8 A | 0.18 kW | 0.8 A | VZA20P1BAA | − |
0.25 kW | 1.6 A | 0.37 kW | 1.6 A | VZA20P2BAA | − | |
0.55 kW | 3.0 A | 0.75 kW | 3.5 A | VZA20P4BAA | − | |
1.1 kW | 5.0 A | 1.1 kW | 6.0 A | VZA20P7BAA | − | |
1.5 kW | 8.0 A | 2.2 kW | 9.6 A | VZA21P5BAA | − | |
2.2 kW | 11.0 A | 3.0 kW | 12.0 A | VZA22P2BAA | − | |
4.0 kW | 17.5 A | 5.5 kW | 21.0 A | VZA24P0BAA | − | |
5.5 kW | 25.0 A | 7.5 kW | 30.0 A | VZA25P5FAA | − | |
7.5 kW | 33.0 A | 11.0 kW | 40.0 A | VZA27P5FAA | − | |
11 kW | 47.0 A | 15.0 kW | 56.0 A | VZA2011FAA | − | |
15 kW | 60.0 A | 18.5 kW | 69.0 A | VZA2015FAA | − | |
3x400 V | 0.37 kW | 1.2 A | 0.37 kW | 1.2 A | VZA40P2BAA | VZA40P2EAB |
0.55 kW | 1.8 A | 0.75 kW | 2.1 A | VZA40P4BAA | VZA40P4EAB | |
1.1 kW | 3.4 A | 1.5 kW | 4.1 A | VZA40P7BAA | VZA40P7EAB | |
1.5 kW | 4.8 A | 2.2 kW | 5.4 A | VZA41P5BAA | VZA41P5EAB | |
2.2 kW | 5.5 A | 3.0 kW | 6.9 A | VZA42P2BAA | VZA42P2EAB | |
3.0 kW | 7.2 A | 4.0 kW | 8.8 A | VZA43P0BAA | VZA43P0EAB | |
4.0 kW | 9.2 A | 5.5 kW | 11.1 A | VZA44P0BAA | VZA44P0EAB | |
5.5 kW | 14.8 A | 7.5 kW | 17.5 A | VZA45P5FAA | − | |
7.5 kW | 18.0 A | 11.0 kW | 23.0 A | VZA47P5FAA | − | |
11 kW | 24.0 A | 15.0 kW | 31.0 A | VZA4011FAA | − | |
15 kW | 31.0 A | 18.5 kW | 38.0 A | VZA4015FAA | − |
Inverter | Standard line filter | Low leakage line filter | |||||||
---|---|---|---|---|---|---|---|---|---|
Schaffner | Rasmi | Schaffner | Rasmi | ||||||
Voltage | Model VZA⬜ | Reference A1000-FIV | Current (A) | Reference A1000-FIV | Current (A) | Reference A1000-FIV | Current (A) | Reference A1000-FIV | Current (A) |
1-Phase 200 VAC | B0P1 / B0P2 / B0P4 | 1010-SE | 10 | 1010-RE | 10 | 1010-SE-LL | 10 | 1010-RE-LL | 10 |
B0P7 / B1P5 | 1020-SE | 20 | 1020-RE | 20 | 1020-SE-LL | 20 | 1020-RE-LL | 20 | |
B2P2 | 1030-SE | 30 | 1030-RE | 30 | 1030-SE-LL | 24 | 1030-RE-LL | 30 | |
B4P0 | 1040-SE | 40 | 1040-RE | 40 | 1040-SE-LL | 40 | 1040-RE-LL | 40 | |
3-Phase 200 VAC | 20P1 / 20P2 / 20P4 / 20P7 | 2010-SE-V1 | 10 | 2010-RE | 10 | 2010-SE-LL | 10 | 2010-RE-LL | 10 |
21P5 / 22P2 | 2020-SE | 14 | 2020-RE | 16 | 2020-SE-LL | 20 | 2020-RE-LL | 16 | |
24P0 | 2030-SE | 24 | 2030-RE | 26 | 2030-SE-LL | 30 | 2030-RE-LL | 26 | |
25P5 / 27P5 | 2060-SE-V1 | 52 | 2060-RE | 60 | − | − | 2060-RE-LL | 60 | |
2011 | 2080-SE-V1 | 68 | 2080-RE | 80 | − | − | 2080-RE-LL | 80 | |
2015 | 2100-SE-V1 | 80 | 2100-RE | 100 | − | − | 2100-RE-LL | 100 | |
3-Phase 400 VAC | 40P2 / 40P4 | 3005-SE | 5 | 3005-RE | 5 | 3005-SE-LL | 5 | 3005-RE-LL | 5 |
40P7 / 41P5 / 42P2 / 43P0 | 3010-SE | 10 | 3010-RE | 10 | 3010-SE-LL | 10 | 3010-RE-LL | 10 | |
44P0 | 3020-SE | 15 | 3020-RE | 15 | 3020-SE-LL | 15 | 3020-RE-LL | 15 | |
45P5 / 47P5 | 3030-SE-V1 | 30 | 3030-RE | 30 | 3030-SE-LL | 30 | 3030-RE-LL | 30 | |
4011 / 4015 | 3050-SE-V1 | 50 | 3050-RE | 50 | 3050-SE-LL | 50 | 3050-RE-LL | 50 |
Inverter | AC Reactor | |
---|---|---|
Voltage | Model VZA⬜ | Reference |
1-Phase 200 VAC | B0P1 / B0P2 / B0P4 | AX-RAI02000070-DE |
B0P7 | AX-RAI01700140-DE | |
B1P5 | AX-RAI01200200-DE | |
B2P2 | AX-RAI00630240-DE | |
B4P0 | − | |
3-Phase 200 VAC | 20P1 / 20P2 / 20P4 / 20P7 | AX-RAI02800080-DE |
21P5 / 22P2 / 24P0 | AX-RAI00880200-DE | |
25P5 / 27P5 | AX-RAI00350335-DE | |
2011 / 2015 | AX-RAI00180670-DE | |
3-Phase 400 VAC | 40P2 / 40P4 / 40P7 / 41P5 | AX-RAI07700050-DE |
42P2 / 43P0 / 44P0 | AX-RAI03500100-DE | |
45P5 / 47P5 | AX-RAI01300170-DE | |
4011 / 4015 | AX-RAI00740335-DE |
200V 1-phase | 200V 3-phase | 400V 3-phase | |||
---|---|---|---|---|---|
Model VZA⬜ | DC Reactor | Model VZA⬜ | DC Reactor | Model VZA⬜ | DC Reactor |
B0P1 | AX-RC10700032-DE | 20P1 | AX-RC21400016-DE | 40P2 / 40P4 | AX-RC43000020-DE |
B0P2 | 20P2 | 40P7 | AX-RC27000030-DE | ||
B0P4 | AX-RC06750061-DE | 20P4 | AX-RC10700032-DE | 41P5 | AX-RC14000047-DE |
B0P7 | AX-RC03510093-DE | 20P7 | AX-RC06750061-DE | 42P2 | AX-RC10100069-DE |
B1P5 | AX-RC02510138-DE | 21P5 | AX-RC03510093-DE | 43P0 | AX-RC08250093-DE |
B2P2 | AX-RC01600223-DE | 22P2 | AX-RC02510138-DE | 44P0 | AX-RC06400116-DE |
B4P0 | − | 24P0 | AX-RC01600223-DE | 45P5 | AX-RC04410167-DE |
- | 25P5 | AX-RC01110309-DE | 47P5 | AX-RC03350219-DE | |
27P5 | AX-RC00840437-DE | 4011 | AX-RC02330307-DE | ||
2011 | AX-RC00590614-DE | 4015 | AX-RC01750430-DE | ||
2015 | AX-RC00440859-DE | − |
Model | Diameter | Description |
---|---|---|
AX-FER2102-RE | 21 | For 2.2 KW motors or below |
AX-FER2515-RE | 25 | For 15 KW motors or below |
AX-FER5045-RE | 50 | For 45 KW motors or below |
Inverter | AC Reactor | |
---|---|---|
Voltage | Model VZA⬜ | Reference |
200 VAC | B0P1 / B0P2 / B0P4 20P1 / 20P2 / 20P4 | AX-RAO11500026-DE |
B0P7 / 20P7 | AX-RAO07600042-DE | |
B1P5 / 21P5 | AX-RAO04100075-DE | |
B2P2 / 22P2 | AX-RAO03000105-DE | |
B4P0 / 24P0 | AX-RAO01830160-DE | |
25P5 | AX-RAO01150220-DE | |
27P5 | AX-RAO00950320-DE | |
2011 | AX-RAO00630430-DE | |
2015 | AX-RAO00490640-DE | |
400 VAC | 40P2 / 40P4 / 40P7 / 41P5 | AX-RAO16300038-DE |
42P2 | AX-RAO11800053-DE | |
43P0 / 44P0 | AX-RAO07300080-DE | |
45P5 | AX-RAO04600110-DE | |
47P5 | AX-RAO03600160-DE | |
4011 | AX-RAO02500220-DE | |
4015 | AX-RAO02000320-DE |
Type | Description | Function | Order code |
---|---|---|---|
Communication option board | DeviceNet option card | Used for running or stopping the inverter, setting or referencing parameters, and monitoring output frequency, output current, or similar items through DeviceNet communication with the host controller. | SI-N3/V |
PROFIBUS-DP option card | Used for running or stopping the inverter, setting or referencing parameters, and monitoring output frequency, output current, or similar items through PROFIBUS-DP communication with the host controller. | SI-P3/V | |
CANopen option card | Used for running or stopping the inverter, setting or referencing parameters, and monitoring output frequency, output current, or similar items through CANopen communication with the host controller. | SI-S3/V | |
MECHATROLINK-II option card | Used for running or stopping the inverter, setting or referencing parameters, and monitoring output frequency, output current, or similar items through MECHATROLINK-II communication with the host controller. | SI-T3/V | |
EtherCAT option card | Used for running or stopping the inverter, setting or referencing parameters, and monitoring output frequency, output current, or similar items through EtherCAT communication with the host controller. | EUOP-SI-ES3/V | |
PROFINET option card | Used for running or stopping the inverter, setting or referencing parameters, and monitoring output frequency, output current, or similar items through PROFINET communication with the host controller. | SI-EP3/V |
Types | Description | Functions | Order code |
---|---|---|---|
Digital operator | LCD remote operator | LCD Display operator with language support | JVOP-180 |
Remote operator cable | 3 meters cable for connecting remote operator | A1000-CAVOP300-EE | |
Accessories | USB converter / USB cable | USB converter unit with copy and backup function | JVOP-181 |
24 VDC option board | 24VDC control board power supply VZA-B/2/4 from 0.1 to 4 KW | PS-V10S | |
24VDC control board power supply VZA-2/4 from 5.5 to 15 KW | PS-V10M | ||
PC connection cable | RS232 PC tool connection cable | A1000-CAVPC232-EE |
Types | Description | Installation | Order code |
---|---|---|---|
Software | Computer software | Configuration and monitoring software tool | CX-Drive |
Computer software | Configuration and monitoring software tool | CX-One |
Inverter | Braking resistor unit | ||||||
---|---|---|---|---|---|---|---|
Voltage | Max. | Inverter model VZA⬜ | Connectable min. resistance Ω | Inverter mounted type (3 %ED, 10 sec max) | Braking torque % | ||
1-phase | 3-phase | Type AX- | Resist Ω | ||||
200 V three-phase) | 0.12 | B0P1 | 20P1 | 300 | REM00K1400-IE | 400 | 135 |
0.25 | B0P2 | 20P2 | 120 | ||||
0.55 | B0P4 | 20P4 | 200 | REM00K1200-IE | 200 | 120 | |
1.1 | B0P7 | 20P7 | 120 | 70 | |||
1.5 | B1P5 | 21P5 | 60 | REM00K2070-IE | 70 | 190 | |
2.2 | B2P2 | 22P2 | 120 | ||||
4.0 | B4P0 | 24P0 | 32 | REM00K4035-IE | 35 | 135 | |
5.5 | − | 25P5 | 16 | 75 | |||
7.5 | − | 27P5 | 9.6 | 55 | |||
11 | − | 2011 | REM00K6035-IE | 35 | 40 | ||
15 | − | 2015 | REM00K9017-IE | 17 | 55 | ||
400 V | 0.37 | − | 40P2 | 750 | 2 x REM00K1400-IE | 800 | 270 |
0.55 | − | 40P4 | 270 | ||||
1.1 | − | 40P7 | 510 | 270 | |||
1.5 | − | 41P5 | 240 | REM00K1400-IE | 400 | 130 | |
2.2 | − | 42P2 | 200 | REM00K2200-IE | 200 | 130 | |
3.0 | − | 43P0 | 100 | REM00K2120-IE | 120 | 215 | |
4.0 | − | 44P0 | 160 | ||||
5.5 | − | 45P5 | 32 | REM00K4035-IE | 35 | 140 | |
7.5 | − | 47P5 | 80 | ||||
11 | − | 4011 | 20 | REM00K6035-IE | 35 | 50 | |
15 | − | 4015 | REM00K9020-IE | 20 | 55 |
Types | Description | Applicable models VZA⬜ | Order code |
---|---|---|---|
DIN Rail | Necessary to mount the inverter on a DIN rail | B0P1/B0P2/B0P4 20P1/20P2/20P4/20P7 | EZZ08122A |
B0P7/B1P5 21P5/22P2 40P2/40P4/40P7/41P5/42P2 | EZZ08122B | ||
B2P2 24P0 44P0 | EZZ08122C | ||
B4P0 | EZZ08122D | ||
Heatsink | Additional items to mount the inverter with the heatsink out of the panel | B0P1/B0P2 20P1/20P2 | 100-034-075 |
B0P4 20P4 | 100-034-076 | ||
20P7 | 100-034-077 | ||
40P2 | 100-034-078 | ||
B1P5 21P5/22P2 41P5/42P2/43P0 | 100-034-079 | ||
B2P2 24P0 44P0 | 100-034-080 | ||
B4P0 | 100-036-357 | ||
B0P7 40P2/40P4 | 100-036-418 | ||
25P5/27P5 45P5/47P5 | 100-036-300 | ||
2011 4011/4015 | 100-036-301 | ||
2015 | 100-036-302 |
Single-phase: VZA⬜ | B0P1 | B0P2 | B0P4 | B0P7 | B1P5 | B2P2 | B4P0 | - | - | - | - | |
---|---|---|---|---|---|---|---|---|---|---|---|---|
Three-phase: VZA⬜ | 20P1 | 20P2 | 20P4 | 20P7 | 21P5 | 22P2 | 24P0 | 25P5 | 27P5 | 2011 | 2015 | |
Motor kW | For HD setting | 0.12 | 0.25 | 0.4 | 1.1 | 1.5 | 2.2 | 4.0 | 5.5 | 7.5 | 11 | 15 |
For ND setting | 0.18 | 0.37 | 0.55 | 1.1 | 2.2 | 3.0 | 5.51 | 7.5 | 11 | 15 | 18.5 | |
Output | Inverter capacity kVA | 0.3 | 0.6 | 1.1 | 1.9 | 3.0 | 4.2 | 6.7 | 9.5 | 13 | 18 | 23 |
Rated output current (A) at HD | 0.8 | 1.6 | 3.0 | 5.0 | 8.0 | 11.0 | 17.5 | 25.0 | 33.0 | 47.0 | 60.0 | |
Rated output current (A) at ND | 1.2 | 1.9 | 3.5 | 6.0 | 9.6 | 12.0 | 19.6 | 30.0 | 40.0 | 56.0 | 69.0 | |
Max. output voltage | Proportional to input voltage: 0..240 V | |||||||||||
Max. output frequency | 400 Hz | |||||||||||
Power | Rated input voltage | Single-phase 200..240 V 50/60 Hz 3-phase 200..240 V 50/60 Hz | ||||||||||
Allowable voltage | -15%..+10% | |||||||||||
Allowable frequency | +5% |
Three-phase: VZA⬜ | 40P2 | 40P4 | 40P7 | 41P5 | 42P2 | 43P0 | 44P0 | 45P5 | 47P5 | 4011 | 4015 | |
---|---|---|---|---|---|---|---|---|---|---|---|---|
Motor kW | For HD setting | 0.37 | 0.55 | 1.10 | 1.5 | 2.2 | 3.0 | 4.0 | 5.5 | 7.5 | 11 | 15 |
For ND setting | 0.37 | 0.75 | 1.5 | 2.2 | 3.0 | 4.0 | 5.5 | 7.5 | 11 | 15 | 18.5 | |
Output | Inverter capacity kVA | 0.9 | 1.4 | 2.6 | 3.7 | 4.2 | 5.5 | 7.2 | 9.2 | 14.8 | 18 | 24 |
Rated output current (A) at HD | 1.2 | 1.8 | 3.4 | 4.8 | 5.5 | 7.2 | 9.2 | 14.8 | 18.0 | 24 | 31 | |
Rated output current (A) at ND | 1.2 | 2.1 | 4.1 | 5.4 | 6.9 | 8.8 | 11.1 | 17.5 | 23 | 31 | 38 | |
Max. output voltage | 0..480 V (proportional to input voltage) | |||||||||||
Max. output frequency | 400 Hz | |||||||||||
Power | Rated input voltage | 3-phase 380..480 VAC, 50/60 Hz | ||||||||||
Allowable voltage | -15%..+10% | |||||||||||
Allowable frequency | +5% |
Voltage class | Max. applicable | Inverter model VZA⬜ | Figure | Dimensions in mm | ||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
W1 | H1 | W | H | D | t1 | H2 | D1 | H3 | H4 | Weight kg | ||||
Single-phase | 0.12 | B0P1 | 1 | 56 | 118 | 68 | 128 | 76 | 3 | 5 | 6.5 | − | − | 0.6 |
0.25 | B0P2 | 0.7 | ||||||||||||
0.55 | B0P4 | 108 | 5 | 38.5 | 1.0 | |||||||||
1.1 | B0P7 | 2 | 96 | 108 | 137.5 | 58 | 1.7 | |||||||
1.5 | B1P5 | 154 | 1.8 | |||||||||||
2.2 | B2P2 | 128 | 140 | 163 | 65 | 2.4 | ||||||||
4.0 | B4P0 | 158 | 170 | 180 | 3.0 | |||||||||
Three-phase | 0.12 | 20P1 | 1 | 56 | 118 | 68 | 128 | 76 | 3 | 5 | 6.5 | − | − | 0.6 |
0.25 | 20P2 | 0.6 | ||||||||||||
0.55 | 20P4 | 108 | 5 | 38.5 | 0.9 | |||||||||
1.1 | 20P7 | 128 | 1.1 | |||||||||||
1.5 | 21P5 | 2 | 96 | 108 | 129 | 58 | 1.3 | |||||||
2.2 | 22P2 | 137.5 | 1.4 | |||||||||||
4.0 | 24P0 | 128 | 140 | 143 | 65 | 2.1 | ||||||||
5.5 | 25P5 | 3 | 122 | 248 | 140 | 254 | 140 | − | 6 | 55 | 13 | 6.2 | 3.8 | |
7.5 | 27P5 | 3.8 | ||||||||||||
11 | 2011 | 160 | 284 | 180 | 290 | 163 | 8 | 75 | 15 | 5.5 | ||||
15 | 2015 | 192 | 336 | 220 | 358 | 187 | 7 | 78 | 7.2 | 9.2 | ||||
Three-phase | 0.37 | 40P2 | 2 | 96 | 118 | 108 | 128 | 81 | 5 | 5 | 10 | − | − | 0.8 |
0.55 | 40P4 | 99 | 28 | 1.0 | ||||||||||
1.1 | 40P7 | 137.5 | 58 | 1.4 | ||||||||||
1.5 | 41P5 | 154 | 1.5 | |||||||||||
2.2 | 42P2 | 1.5 | ||||||||||||
3.0 | 43P0 | 1.5 | ||||||||||||
4.0 | 44P0 | 128 | 140 | 143 | 65 | 2.1 | ||||||||
5.5 | 45P5 | 3 | 122 | 248 | 140 | 254 | 140 | − | 6 | 55 | 13 | 6 | 3.8 | |
7.5 | 47P5 | 6.2 | 3.8 | |||||||||||
11 | 4011 | 160 | 284 | 180 | 290 | 143 | 8 | 15 | 6 | 5.2 | ||||
15 | 4015 | 163 | 75 | 5.5 |
VZA⬜ | Dimensions in mm | |||||
---|---|---|---|---|---|---|
W | H | H1 | D1 | D2 | D | |
B0P1 | 68+ | 178 | 50 | 69.5 | 6.5 | 76 |
B0P2 | ||||||
B0P4 | 79.5 | 38.5 | 118 | |||
B0P7 | 108 | 77.9 | 59.6 | 137.5 | ||
B1P5 | 89.4 | 64.6 | 154 | |||
B2P2 | 140 | 183 | 55 | 96.4 | 66.6 | 163 |
40P2 | 108 | 178 | 50 | 69.4 | 11.6 | 81 |
40P4 | 29.6 | 99 | ||||
40P7 | 77.9 | 59.6 | 137.5 | |||
41P5 | 94.4 | 154 | ||||
42P2 | ||||||
43P0 | ||||||
44P0 | 140 | 183 | 55 | 76.4 | 66.6 | 143 |
Titre: | Taille: | Type: |
---|---|---|
PDF CATALOGUE OMRON FR.pdf | 88 Mbytes |
![]() |
Aucun commentaire sur le produit encore.
Score: |
![]() ![]() ![]() ![]() ![]() |
Nom: | |
Email: | |
Titre: | |
Commentaire: | |
Recommandez-vous acheter ce produit? | |
|
|
Écrire commentaire |
Toutes les évaluations que nous recevons des articles que nous proposons sont réels et vérifiés. Un petit geste, mais très précieux. Je vous remercie pour cette minute que vous passez à nous laisser votre avis et note sur les produits, car il nous aide à continuer à améliorer et à offrir encore plus la qualité de service.
