PC 5/ 3-ST2-7,62 BK2CPBDNZ5774
1834290
PHOENIX_CONTACT
50
Conector para placa de circuito impresso, corrente nominal: 41 A, tensão de teste (III/2): 1000 V, número de polos: 3, passo: 7,62 mm, tipo de conexão: Conexão por rosqueamento com luva de tração, cor: preto, superfície de contato: Estanho
PCB connector, nominal current: 41 A, rated voltage (III/2): 1000 V, nominal cross section: 6 mm², number of positions: 3, pitch: 7.62 mm, connection method: Screw connection with tension sleeve, color: black, contact surface: Tin
Conectores PCB
* Produto novo em sua embalagem original com todas as garantias e certificações de PHOENIX_CONTACT
Obrigado pelo seu interesse nos nossos artigos, esperamos que o prazo indicado seja conveniente para si.
Durante a preparação do pedido pode seleccionar o tipo de envío que melhor se adapte ás suas necessidades: Aéreo Express 24Hrs, Terrestre Standard 48/72Hrs, etc.
Chave de encomenda | 1834290 |
---|---|
Quantidade de embalagem | 1 |
GTIN (EAN) | 4046356965392 |
Número do imposto alfandegário | 85366990 |
Brief article description | Printed-circuit board connector |
---|---|
Plug-in system | POWER COMBICON 5 |
Type of contact | Female connector |
Range of articles | PC 5/..-ST1 |
Pitch | 7.62 mm |
Number of positions | 3 |
Connection method | Screw connection with tension sleeve |
Drive form screw head | Philipps recess with slotted Torx (H1L) |
Screw thread | M3 |
Locking | without |
Number of levels | 1 |
Number of connections | 3 |
Number of potentials | 3 |
Nominal current | 41 A |
---|---|
Nom. voltage | 1000 V |
Rated voltage | 1000 V |
Rated voltage (III/2) | 1000 V |
Rated voltage (II/2) | 1000 V |
Rated surge voltage (III/3) | 8 kV |
Rated surge voltage (III/2) | 8 kV |
Rated surge voltage (II/2) | 6 kV |
Connection method | Screw connection with tension sleeve |
---|---|
pluggable | Yes |
Conductor cross section solid | 0.2 mm² ... 10 mm² |
Conductor cross section flexible | 0.2 mm² ... 6 mm² |
Conductor cross section AWG / kcmil | 24 ... 10 |
Conductor cross section flexible, with ferrule without plastic sleeve | 0.25 mm² ... 6 mm² |
Conductor cross section, flexible, with ferrule, with plastic sleeve | 0.25 mm² ... 4 mm² |
2 conductors with same cross section, solid | 0.2 mm² ... 2.5 mm² |
2 conductors with same cross section, flexible | 0.2 mm² ... 4 mm² |
2 conductors with same cross section, flexible, with ferrule without plastic sleeve | 0.25 mm² ... 1.5 mm² |
2 conductors with the same cross section, flexible, with TWIN ferrule with plastic sleeve | 0.25 mm² ... 2.5 mm² |
Stripping length | 10 mm |
Torque | 0.5 Nm ... 0.8 Nm (≤ 4 mm² is 0.5 Nm to 0.6 Nm, > 4 mm² is 0.7 Nm to 0.8 Nm) |
Note | WEEE/RoHS-compliant, free of whiskers according to IEC 60068-2-82/JEDEC JESD 201 |
---|---|
Contact material | Cu alloy |
Surface characteristics | hot-dip tin-plated |
Metal surface terminal point (top layer) | Tin (4 - 8 µm Sn) |
Metal surface contact area (top layer) | Tin (4 - 8 µm Sn) |
Housing color | black (9005) |
---|---|
Insulating material | PA |
Insulating material group | I |
CTI according to IEC 60112 | 600 |
Flammability rating according to UL 94 | V0 |
Glow wire flammability index GWFI according to EN 60695-2-12 | 850 |
Glow wire ignition temperature GWIT according to EN 60695-2-13 | 775 |
Temperature for the ball pressure test according to EN 60695-10-2 | 125 °C |
Dimensional drawing | |
---|---|
Length [ l ] | 35.25 mm |
Width [ w ] | 22.81 mm |
Height [ h ] | 19.7 mm |
Pitch | 7.62 mm |
Height (without solder pin) | 19.7 mm |
Dimension a | 15.24 mm |
Type of packaging | packed in cardboard |
---|---|
Pieces per package | 50 |
Denomination packing units | Pcs. |
Ambient temperature (storage/transport) | -40 °C ... 70 °C |
---|---|
Ambient temperature (assembly) | -5 °C ... 100 °C |
Ambient temperature (operation) | -40 °C ... 100 °C (dependent on the derating curve) |
Test for conductor damage and slackening | IEC 60999-1:1999-11 |
---|---|
Test passed |
Pull-out test | IEC 60999-1:1999-11 |
---|---|
Test passed | |
Conductor cross section / conductor type / tensile force | 0.2 mm² / solid / > 10 N |
0.2 mm² / flexible / > 10 N | |
6 mm² / solid / > 80 N | |
4 mm² / flexible / > 60 N | |
6 mm² / flexible / > 80 N | |
10 mm² / solid / > 90 N |
Visual examination | Test passed IEC 60512-1-1:2002-02 |
---|---|
Dimensional test | Test passed IEC 60512-1-2:2002-02 |
Resistance of marking | Test passed IEC 60068-2-70:1995-12 |
Result | Test passed |
Specification | IEC 60512-13-2:2006-02 |
No. of cycles | 50 |
Insertion strength per pos. approx. | 8 N |
Withdraw strength per pos. approx. | 4 N |
Polarization and coding | Test passed IEC 60512-13-5:2006-02 |
Result | Test passed |
Specification | IEC 60512-15-1:2008-05 |
Test force per pos. | 29 N |
Clearances and creepage distances | IEC 60664-1:2007-04 |
---|---|
Specification | IEC 60664-1:2007-04 |
Minimum clearance - inhomogeneous field (III/3) | 8 mm |
Minimum clearance - inhomogeneous field (III/2) | 8 mm |
Minimum clearance - inhomogeneous field (II/2) | 5.5 mm |
Minimum creepage distance value (III/3) | 12.5 mm |
Minimum creepage distance value (III/2) | 5 mm |
Minimum creepage distance value (II/2) | 5 mm |
Insertion strength per pos. approx. | 8 N |
---|---|
Withdraw strength per pos. approx. | 4 N |
Polarization when inserted requirement >20 N | Test passed |
Contact holder in insert requirements >20 N | Test passed |
Specification | IEC 60512-9-1:2010-03 |
---|---|
Contact resistance R1 | 0.4 mΩ |
Insertion/withdrawal cycles | 50 |
Contact resistance R2 | 0.4 mΩ |
Impulse withstand voltage at sea level | 7.3 kV |
Power-frequency withstand voltage | 3.31 kV |
Insulation resistance, neighboring positions | > 34 TΩ |
Specification | ISO 6988:1985-02 |
---|---|
Cold stress | -40 °C/2 h |
Thermal stress | 100 °C/168 h |
Corrosive stress | 0.2 dm3SO2on 300 dm3/40 °C/1 cycle |
Impulse withstand voltage at sea level | 7.3 kV |
Power-frequency withstand voltage | 3.31 kV |
Specification | IEC 61984:2008-10 |
---|---|
Result, degree of protection, IP code | Back of hand safety with IP10 access probe |
REACh SVHC | Lead 7439-92-1 |
---|---|
China RoHS | Environmentally Friendly Use Period = 50 years |
For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” |
